Fruit vegetable Grading Equipment

Automatic fruit vegetable sorting and grading machine uses the principle of lifting rollers, using a series of forward-moving stainless steel rollers, a fixed-bottom roller and a height-adjustable roller to grade crops according to width and diameter. Each and the second roller are mounted on a polymer guide plate, which enables them to be raised and lowered vertically to achieve grade size sorting. The size of the grader can be adjusted at will.

  • ODM
  • 7*24-Hour Service
  • Full Range
  • After Sales Service

Advantages

Fruit vegetable Grading Equipment Video

Technical Parameters

ParameterDetails
Product NameAutomatic Fruit vegetable Sorting and Grading Machine
Applicable MaterialsOranges, Apples, Carrots, Avocados, and other fruits and root vegetables
Application FieldsFruit vegetable processing facilities, agricultural operations, packing houses, and distribution centers
Grading AdjustmentGrading size can be adjusted arbitrarily to meet specific requirements
MaterialConstructed with food-grade stainless steel and polymer guide plates
Power Supply220V/380V, 50Hz/60Hz (customizable based on requirements)
WeightApproximately 500 kg
Warranty1 year
Core ComponentsMotor, PLC (Programmable Logic Controller)
Customization OptionsAvailable to tailor the machine to specific sorting requirements
video outgoing-inspectionProvided
machinery test reportProvided


Note: Technical specifications may change without notice due to ongoing technological advancements.

Applications

Please feel free to contact us at any time to request a quotation and obtain more detailed information about our products and services.
